ATTO ThunderLink NT 2102
20Gb/s Thunderbolt 2 (2-port) to 10GbE (2-Port) Adapter (10GBASE-T)

ATTO ThunderLink NS 2102

ATTO Technology Products
ATTO ThunderLink Thunderbolt Adapters
USA: FREE Ground ShippingATTO ThunderLink NT 2102 Dual 20Gb to Dual 10Gb Ethernet Thunderbolt 2 Adapter, RJ45 Interface
#TLNT-2102-D00
Our Price: $695.00
USA: FREE Ground ShippingATTO ThunderLink NT 2102 Dual 20Gb to Dual 10Gb Ethernet Thunderbolt 2 Adapter, RJ45 Interface, IEC C-13 power cord included
#TLNT-2102-DE0
Our Price: $695.00

Click here to jump to more pricing!

Overview:

The ATTO ThunderLink NT 2102 acts as an external Thunderbolt 2 to copper RJ45 based copper 10GbE adapter, connecting Thunderbolt enabled workbooks and workstations to copper 10Gb/s Ethernet networks and storage devices. ThunderLink 10GbE, with support for link aggregation and failover, offers redundancy and high availability for critical network applications. With 10Gb/s data transfer rates and multiple offloads (TCP, IPv4, UDP), Ethernet Thunderlinks are the premier connectivity choice for bandwidth-intensive applications such as data back-up and restoration, clustered computing, IP content delivery, medical imaging, and video rendering. With multi-core processors driving the need for higher bandwidth, ThunderLink 10GbE delivers superior throughput to meet that need.

With a low profile form factor, and Thunderbolt 2 dual-port connectivity, ATTO's optical 10GbE ThunderLink provides the most flexible and scalable connectivity for today's high bandwidth content creation environments. By leveraging support for software iSCSI initiators, including ATTO Xtend SAN, ThunderLink® 10GbE can support both local and storage area networks.

ThunderLink 10GbE offers Windows and Mac certified drivers, providing a single connectivity solution for customers with multiple operating system environments.

All ATTO Thunderbolt product utilize Advanced Data Streaming (ADS) Technology which maximizes CPU processes to deliver smooth and reliable data transfers and the highest consistent performance as well as our easy to use ConfigTool, an intuitive GUI, which enables management, monitoring and configuration.

Technical Features

  • Exclusive Advanced Data Streaming (ADS) technology which smooths data transfers
  • Minimized interrupts for low latency
  • Interoperability tested with Tier 1 storage vendors
  • Industry's lowest power consumption
  • Single configuration tool which runs across multiple products and operating systems to manage devices
  • Support tools for diagnosing technical issues and resolving them in a timely mannner
  • Three year standard product warranty
  • Supports ATTO Xtend SAN iSCSI initiator
  • Dual 10BASE-T (RJ45 Copper) ports
  • Supports 4K video file transfer and display simultaneously with dual 20Gb/s Thunderbolt 2
  • Daisy chain up to five additional Thunderbolt technology enabled devices
  • Backwares compatible with 10Gb/s Thunderbolt
  • TCP, UDP, and IPv4 checksum offloading and Tx/TCP segmentation offloading
  • RoHS Compliant

Industry Proven Technology

ATTO Technology has 30 years of experience developing and delivering first-to-market high performance and reliable storage connectivity solutions for customers. ATTO ThunderLink Ethernet adapters now provide creative professional using Thunderbolt enabled hosts, cost effective access to storage not previously available using FireWire or USB. The integrated family of ThunderLink adapters boasts an extensive list of customer design wins and certifications with respected industry partners.

Flexible Connectivity Solutions

ATTO 10GbE adapters provide the most flexible and scalable connectivity for today's high bandwidth content creation environments. By leveraging support for software iSCSI initiators, including ATTO Xtend SAN, ThunderLink 10GbE adapters can support both local and storage networks. ThunderLink 10GbE adapters offer driver support for Windows and macOS, VMware, providing a single connectivity solution for customers with heterogeneous operating system environments.

Performance Engineered

With 10Gb data transfer rates and multiple offloads (TCP, IPv4, UDP), ATTO Ethernet adapters are the premier connectivity choice for bandwidth-intensive applications such as data back-up and restoration, IP content delivery, medical imaging, and video rendering. With mult-core processors driving the need for higher bandwidth, ThunderLink 10GbE adapters deliver superior throughput to meet that need.

Advanced Management Tools

ThunderLink 10GbE adapters provide a common foundation for both Ehternet and storage networks. The ThunderLink leverages standard OS management and monitoring tools to dramatically reduce the cost and complexity of a data center's administration and infrastructure.

Applications

ThunderLink 10GbE adapter solutions allow the unparalleled performance of 10GbE, the lossless benefits of enhanced Ethernet and robustness of iSCSI initiator software, to meet the performance and economic needs to today's growing data centers. The ThunderLink is ideal for applications that require low latency, high bandwidth data transfers, such as data back-up and restoration, video-on-demand and video streaming, medical imaging, and clustered databases.

Advanced Data Streaming (ADS)

Latency-management technology that controls the acceleration of data transfers to move large amounts of data faster and more efficiently.

Design:

ATTO ThunderLink Fibre Channel adaptersPurpose-built with your design needs in mind

Meet demands for increased portability, decreased footprint and noise-sensitive environments with a low profile, cool, ultra-quiet device. ThunderLink adapters are simple to stack, easy to install and are designed to integrate seamlessly into existing infrastructures. The ability to hot-plug and full support of daisy-chaining allows you to reconfigure on-the-fly and empowers scalability as workgroups grow.

Spend less time managing equipment and more time creating

Trust your units are powered, ready-to-go and have uninterrupted power with locking power supplies. Now shipping with every Thunderbolt adapter, Kensington Security Slots provide a simple solution for studios, offices and educational facilities, allowing units to be easily secured to a fixed location.

Performance:

An investment in a ThunderLink comes with knowing our team of experts has sweat the finest of details to provide you superior performance, design and ease of use over the competition.

It's time to watch your throughput grow

Finally combat compressed schedules and allow for more time creating high-quality deliverables by optimizing performance, up to 2750MB/s for Thunderbolt 3. Smooth and reliable data delivery via ATTO Advanced Data Streaming (ADS) technology allows you to maintain the highest consistent performance while working with HD, 2K, 4K and higher formats.

Advanced Data Streaming (ADS)

Interoperability:

Build out a workflow the way you need it

Expand your connectivity choices with the widest portfolio of Thunderbolt adapters across Fibre Channel, Ethernet and SAS and 4X more interoperable components than the closest competitors. Any needed optics (SFP+, QSFP+) are already included and rigorously tested to ensure compatability and data integrity. Mac and Windows Thunderbolt certification enables collaborative workflows and the only Thunderbolt adapter certified with VMware ESXi allows deployments of a one-of-a-kind solution for test and development environments.

ATTO Thunderbolt 16Gb Adapter Interoperable Storage Systems

Thunderbolt
Thunderbolt Solutions have never been easier

Improve overall workflow efficiencies using ATTO MultiPath Director drivers for Fibre Channel by providing uninterrupted and consistent data by enabling load balancing and failover. ATTO ConfigTool provides an easy to use, yet powerful GUI for customizing, managing and optimizing your products. Backed by our extensive history and expertise in connectivity solutions, if any issues do arise, we have an on-site support team ready to diagnose technical issues and resolve them in a timely manner.

Specifications:

ATTO ThunderLink

ATTO ThunderLink TLNS-2101
Transfer Rate 20Gb/s
Input Connectors (2) 20Gb/s Thunderbolt
Output Connectors (2) 10GbE Ethernet
Connector Type Thunderbolt 2/RJ45
Form Factor Desktop
General Features
  • Data rate per port: 10GbE
  • TCP, UDP, IPv4, and IPv6 checksum offloading
  • Tx/TCP segmentation offload (Large Send Offload-LSO)
  • Low latency interrupts
  • Interrupt Moderation
  • Interrupt levels INTA, MSI, MSI-X
  • Data Center Bridging (DCB) support
  • Priority-Based Flow Control 802.1Qbb rev.0
  • Enhanced Transmission Selection 802.1Qaz rev.0 protocol
  • Header splits and Replication in Receive
  • Receive Side Scaling for multiple Rx queues
  • Direct Cache Access (DCA) eliminates cache missed and reduces CPU load
  • IEEE 802.3 2005 flow control support
  • 802.1p - Priority Encoding
  • 802.1q - VLAN Tagging
  • 802.3ad - Link Aggregation
  • Override MAC Address
  • VLAN support with tag insertion and stripping
  • Plug and play specification support
  • Advanced Packet Filtering
Advanced Software Features
  • Adaptive load balancing
  • Teaming support
  • PCI Hot Plug/Active peripheral interconnect
Management Tools
  • Easy system monitoring with Simple Network Management Protocol (SNMP) and Remote Network Monitoring (RMON) Statistic Counters
  • Watchdog timer for chip/driver status monitoring
External Connectivity
  • 10Gb/s, 1Gb/s, 1000Mb/s two RJ45 connectors
  • Two LED indicator per port
  • LED Indicators: LINK (solid), ACTIVITY (blinking), LINK SPEED (green = 10GBASE-T, yellow = 1000GBASE-T, off = 100GBASE-TX)
Network Standards
  • IEEE802.3an-2006 (10GBASE-T)
  • IEEE802.1qbb (Priority Encoding)
  • IEEE802.1qaz (Enhanced Transmission)
  • DCBX Protocol
Operating System Support
  • Windows
  • macOS
Compliance
  • FCC Part 15, Subpart B, Class B
  • EN55032, ClassB/EN55024
  • EN60950-1
  • cTUVus
  • EU RoHS (2011/95/EC)
  • TAA Compliant (country of origin:USA)
Dimensions 8.66"(D) x 4.07"(W) x 1.20"(H)
Power Adapter
  • Input: 100-240VAC, 50-60Hz, 0.6A Max
  • Output: 12VDC
Hardware Operating Temperature
  • Temperature: 0°-40° C (34°-104° F)
  • Humidity: 10%-90% non-condensing
Storage Operating Temperature
  • Temperature: -40°-70° C (-40°-157° F)
  • Humidity: 5%-95% non-condensing
Warranty Three-year standard product warranty
Complementary Products
  • ATTO Celerity Fibre Channel HBAs
  • ATTO ExpressSAS HBAs and RAID Adapters
  • ATTO FastFrame NICs
  • ATTO FibreBridge Fibre Channel Bridges
  • ATTO premium cables

Video:

The ATTO Difference - Advanced Data Streaming

Latency management technology is built into ATTO host bus adapters (HBAs) and RAID hardware. Advanced Data Streaming manages latency by providing controlled acceleration for smooth data streaming to maintain the highest consistent performance. ADS ensures best-in-industry data transfers for high-bandwidth applications.



ATTO ThunderRack Rackmount Shelf:

Seamless Rackmount Solutions

Looking for a way to mount and organize Thunderbolt ThunderLink Adapters?

ThunderRack shelving enclosure gives the ability to easily rack units, whether in an on-set cart or standard rack in the data center. Now you can seamlessly integrate ThunderLink adapters into existing workspaces and keep units safe and secure all while freeing up desktop space.

Specifications

  • Fits up to four ATTO ThunderLink Adapters
  • Slim 1U form-factor
  • Fits traditional 19" rack environment
  • Rack 21" depth , extend 32" with included L-Bracket or optional rail kit
  • Note: Cabinet depth must be 26" or higher to use rail kit
  • Easily manage power supplies
  • Simple access to single-sided Thunderbolt and protocol ports
  • Designed for optimal airflow
  • Operating temperature recommendation is 0 - 30C for all models

ATTO ThunderRack Rackmount Shelf

Documentation:

Download the ATTO ThunderLink NT 2102 Datasheet (.PDF)
